MG 5 / MG5 EV Charging Guide: Home Charging, Public Charging and Cable Selection

The MG 5, often written as MG5 EV in the UK, is one of the most practical electric cars to have been sold here: a full battery-electric 5-door estate rather than a crossover or hatchback. It is now discontinued as a new UK model, but it remains popular on the used market because it combines a large boot, sensible range and straightforward charging hardware.

For charging, the most important point is that not every MG5 EV has the same battery or charging specification. Early UK cars used a smaller battery, later Long Range versions moved to a 61.1 kWh pack, and facelift SE and Trophy models introduced further updates. This guide explains how those differences affect home charging, public charging and cable selection.

View MG 5 / MG5 EV Charging Cables

MG 5 / MG5 EV Battery and Charging Specifications

The UK-market MG5 EV is a BEV, meaning it is a full battery-electric vehicle with no petrol engine. It should not be confused with MG5 petrol saloons sold in some other countries. UK MG5 EV models use a Type 2 connection for AC charging and CCS Combo 2 for DC rapid charging.

The charge port is positioned at the front of the car, in the nose or front grille area. This can be convenient on driveways and at many rapid chargers, but it also means cable length and parking orientation matter. If you normally reverse into a space or use an untethered public charger, choose a cable length that comfortably reaches the front of the car without being stretched.

As a practical headline, most UK MG5 EV owners should think in terms of Type 2 AC charging at home, work and many public posts, plus CCS rapid charging for longer journeys. The rapid charger has its own tethered CCS cable, so you do not use your own Type 2 cable for DC rapid charging.

Battery Options

The MG5 EV’s battery depends on age and trim. Before comparing charging times, it is worth identifying which version you own.

Original MG5 EV, approximately 2020-2021: early UK cars are commonly listed with a battery of around 52.5 kWh gross, with about 48.8 kWh usable capacity. WLTP range was around 214 miles, with real-world range depending heavily on speed, temperature and load.
Pre-facelift MG5 EV Long Range, approximately 2021-2022: Long Range versions used a 61.1 kWh battery. Published figures vary by source, with usable capacity generally listed at around 57 kWh. WLTP range was up to about 250 miles.
Facelift MG5 EV Long Range, approximately 2022-2025: later SE and Trophy cars also used a 61.1 kWh battery, with around 57.4 kWh usable capacity. SE models are commonly quoted at up to 250 miles WLTP, while Trophy models are usually quoted at up to 235 miles WLTP, mainly because of trim and wheel specification differences.

If you are buying a used MG5 EV, check the registration date, trim name and owner’s manual. The difference between an early 52.5 kWh car and a later Long Range model is significant enough that one universal charging or range figure would be misleading.

AC Charging Speed

For UK article guidance, 7 kW Type 2 AC charging is the safest headline figure for the MG5 EV, particularly because MG brochure and review sources list a 7 kW onboard charger for the facelift Long Range. Most UK home wallboxes are rated at up to 7.4 kW on single-phase electricity, which is a good match for this sort of onboard charger.

There is some source variation for later cars, with some databases listing higher AC capability for the 2022-2025 Long Range. Because of that conflict, owners should check their handbook, VIN-specific information or MG documentation before assuming their car needs, or can benefit from, a 3-phase cable for faster AC charging.

In day-to-day use, a Type 2 to Type 2 cable is the correct cable type for untethered home chargers, workplace chargers and most public AC charging posts. If you have a tethered home wallbox, the cable is already attached to the charger, but a separate Type 2 cable is still useful for public AC charging.

DC Rapid Charging Speed

DC rapid charging uses the CCS connector at the same front charging location. You do not bring your own rapid charging cable; the cable is permanently attached to the rapid charger.

Rapid charging figures vary by MG5 EV version. For the facelift Long Range cars, official-style brochure information lists up to 87 kW DC charging and a 10-80% charge in around 35 minutes on a suitable high-power charger. In the real world, it is more sensible to allow about 35-45 minutes for a 10-80% session, depending on charger output, battery temperature, state of charge and site conditions.

Earlier Long Range models have been listed with different rapid charging figures by different sources, so avoid assuming that every MG5 EV will charge at the same peak rate. As with most EVs, the peak charging speed is not held for the whole session. Charging from 10-80% is usually the most time-efficient window on a journey; charging beyond 80% often slows noticeably.

Range and Efficiency

The official WLTP range for the MG5 EV runs from around 214 miles on early cars to up to about 250 miles on Long Range versions. Facelift SE models are commonly listed at up to 250 miles WLTP, while Trophy models are typically listed at up to 235 miles WLTP.

Real-world range will usually be lower than the headline WLTP figure. A sensible expectation for a Long Range model is around 200 miles in mixed conditions, with more possible in warm weather and gentle driving, and less during winter motorway use. The estate body shape is practical, but roof bars, roof boxes, heavy loads and high motorway speeds can all reduce efficiency.

For planning, it is better to think in usable range bands rather than exact figures. If you are commuting and returning home to charge overnight, the MG5 EV’s range is likely to be more than enough for many drivers. For long trips, plan rapid charging stops based on a comfortable arrival buffer rather than waiting until the battery is very low.

Charging at Home

A dedicated home wallbox is usually the most convenient way to charge an MG5 EV. On a typical 7 kW or 7.4 kW UK wallbox, an overnight charge will cover most use cases. Charging from a low state of charge to full will take longer than simply adding the energy used during the day, so many owners do not need to charge from near-empty very often.

If your wallbox is untethered, you will need a Type 2 to Type 2 charging cable. A 5 metre cable is often enough where the charger is close to the parking space, while a longer cable may be more convenient if the charger is mounted on a side wall, if you park in different orientations, or if the front charge port is not always closest to the charger.

A 3-pin charger is generally best suited as a backup or occasional charging solution, but can be used regularly if a qualified electrician has confirmed the socket and electrical installation are suitable for sustained EV charging. Standard domestic sockets were not primarily designed for repeated long-duration high-load EV charging, so professional checking is important.

Public Charging

Public AC charging usually requires your own Type 2 cable unless the unit is tethered. These chargers are common in car parks, workplaces, hotels and town centres. They are useful when the car will be parked for several hours, but they are not the quickest option for motorway-style stops.

For longer journeys, use CCS DC rapid chargers. The MG5 EV’s front charge port can make it easy to nose into many rapid charging bays, although charger layouts vary. If a bay is designed with cables on one side, you may need to park carefully so the tethered CCS cable reaches comfortably.

When comparing public chargers, remember that a charger rated higher than the car’s maximum rapid charging capability will not force the MG5 EV to charge faster than the vehicle allows. A 150 kW charger can still be useful, but the car will control the actual power it accepts.

Vehicle-Specific Features

The MG5 EV is notable because it offered electric estate practicality at a relatively accessible price. Many versions have a large boot and roof rails, making the car attractive to families, dog owners and drivers who need load space without moving into an SUV.

Later facelift Long Range models added Vehicle-to-Load capability according to MG launch material and reviews. This feature allows the car to power external devices when used with the correct external adapter. It should not be assumed for every MG5 EV, as earlier versions are listed as not supporting V2L. If V2L matters to you, confirm it on the exact car and ensure you have the correct compatible adapter.

No vehicle-to-grid or vehicle-to-home support is confirmed for the MG5 EV in the research data, so it should not be bought on the assumption that it can act as a home energy storage system.

Charging Tips

Identify your MG5 EV version first: early 52.5 kWh cars, pre-facelift Long Range cars and facelift SE/Trophy Long Range cars have different battery and charging details.
Use Type 2 for AC charging: this is the correct connection for home, workplace and most destination chargers.
Use CCS for rapid charging: DC rapid chargers have tethered CCS cables, so your own Type 2 cable is not used for rapid charging.
Do not over-focus on peak kW: charging time depends on the whole charging curve, battery temperature and state of charge, not just the maximum advertised rate.
Consider cable length: because the port is at the front, a longer Type 2 cable can be useful if your parking layout changes.
Check before buying a 3-phase cable specifically for speed: UK MG5 EV AC charging data differs by source, so confirm your car’s onboard charger specification before assuming 3-phase AC will be faster.

Frequently Asked Questions

Is the MG5 EV a plug-in hybrid?

No. The UK MG5 EV covered here is a full battery-electric vehicle. It charges from an external power supply and has no petrol engine.

What charging cable does the MG5 EV use?

For AC charging, the MG5 EV uses a Type 2 connection. A Type 2 to Type 2 cable is suitable for untethered home wallboxes and most public AC charging posts. For DC rapid charging, the car uses CCS Combo 2 and the cable is attached to the rapid charger.

How fast does the MG5 EV charge at home?

Most UK guidance should assume around 7 kW AC charging, which matches a typical single-phase home wallbox. Exact charging time depends on the battery size, starting charge level and the car’s onboard charger specification.

How long does rapid charging take?

For facelift Long Range models, a 10-80% rapid charge is commonly quoted at around 35 minutes in ideal conditions, but 35-45 minutes is a more realistic planning range. Earlier versions may differ.

Does every MG5 EV have Vehicle-to-Load?

No. V2L is associated with later facelift Long Range cars and requires the correct external adapter. Earlier MG5 EV versions should not be assumed to support it.

What This Means for Drivers

The MG5 EV is straightforward to live with if you match your expectations to the version you own. Early cars have a smaller battery and shorter official range, while Long Range models offer more flexibility for commuting and longer trips. For most drivers, the ideal charging setup is a 7 kW home wallbox, a suitable Type 2 cable for untethered AC charging, and occasional CCS rapid charging on longer journeys.

The main caution is specification variation. Before quoting exact charging times or buying a cable specifically for 3-phase charging, check the car’s model year, trim and handbook. Once that is confirmed, the MG5 EV remains one of the more practical used electric cars in the UK, especially for drivers who want estate space without giving up simple EV charging.
